AG(Array Grain) wheel.
The outstanding sharpness prevents clogging and burn mark, and the service life is more than twice as long as that of conventional Electroplated. It can be used for profile type and is effective in a wide range of machining operations from roughing to finishing.

Features
1) Good chip evacuation
(2) Stable grindability
(3) Excellent wear resistance and long life
(4) Truing with Electroplated truer is possible (limited to CBN ).

High-precision electroplated reamer with micron-level control of tool outer diameter accuracy and good machining accuracy.
Using a machining center that does not require a dedicated machine, high-efficiency is achieved by one-pass processing.

Vitrsoft is a vitrified bond wheel with very good dressability for grinding jigs and molds of HSS and die steel, replacing general firing wheels.CBN Vitrified bond wheel. It can be easily formed by a single point dresser and offers higher efficiency and longer life than general fired wheels (WA).

AZ Life is a new bond with improved bond strength, which achieves the same level of sharpness and a significantly longer service life compared to conventional products.

CBNVitrified bond wheels are manufactured in a variety of sizes, from small-diameter wheels of φ10 mm or less to large-diameter wheels of φ1000 mm, and are widely used in a wide range of applications, including the machining of various automobile parts and the internal grinding of bearings. We also support various applications such as form grinding wheels for angular grinding, centerless wheels, and double-disc wheels with hexagonal pellets.

In the machining of precision parts and mechanical parts made of ceramics and other materials, the technology of uniformly dispersing abrasive grains in the abrasive grain layer has made it possible to improve sharpness while maintaining a long service life, compared to conventional metal tools.
In addition, the ultra-thin abrasive grain layer reduces machining load and chipping in the machining of hard and brittle materials and other special materials, thereby improving machining efficiency and demonstrating its superiority over other tools.

Vitrified grinding wheel using general abrasive grains. A wide variety of wheel configurations from soft to hard are possible, and they are effective as dressing materials for metal tools.

Thin-blade type band saw with diamond electroplated on a high-tensile steel band. It cuts large-diameter silicon ingots and other large-diameter work materials efficiently with high precision. It is also used for cutting carbon, ceramics, glass, and other materials, and can be manufactured in sizes compatible with various machines.
The segment type is suitable for cutting brittle materials and has excellent cutting performance and long life. It is especially suitable for high-precision and high-efficiency cutting of single crystal silicon.
The serrated type is widely used for wide products and demonstrates excellent sharpness for cutting difficult-to-cut materials, and is also ideal for cutting work materials that are prone to blade edge clogging.
The continuous type is used for a wide range of applications from narrow to wide products. The continuous electroplated layer on the cutting edge reduces saw marks on the cutting surface of the work material and is effective in cutting hard work materials.
